7.3 Setting the Main RS-232 Port 33
7.2.3 To Exit Setup Menus
To exit any configuration menu without saving, press any of the upper row of keys before pressing
ENTER (which installs a new value). To return to the configuration menus, press SETUP again.
If you make a configuration error, you can scroll through the menus again and press ENTER when
you find the menu you want to change.
7.3 Setting the Main RS-232 Port
Press SETUP key to configure the main RS-232 port, and press the ENTER key to begin setting
up the RS-232 port parameters (See Figure 7.1). To set up the broadcast mode, press SETUP and
skip to Section 7.3.2 below.
NOTE: port settings may not be changed in the 1092A/C and 1093A series clocks since they do
not have a keypad, and there are no port setting commands.
SET PORT CONFIG?
SETUP
ENTER
SET MAIN RS232?
ENTERSETUP
(To open port configuration)
(To set up Broadcast mode)
Figure 7.1: Main RS-232 Setup
