A.6 Operator Interface 91
A.6 Operator Interface
A.6.1 Setup Methods
• Via RS-232C Interface
• 8 Front-panel keys (Models 1092B and 1093B/C)
A.6.2 Setup Functions
Initial Position System Delays Position Hold
RS-232 Parameters Programmable Pulse Option Control
Local Hour IRIG Time Data –
Out-of-Lock Indication Event/Deviation –
Backlight Auto Survey –
Table A.1: Setup Functions Listed
A.6.3 Display
• 2-line by 20-character supertwist LCD
• Backlight available (Option 01)
• Model 1092C and 1093C include a large LED time display
A.6.4 Display Functions
• Time: UTC or Local
• 1 PPS (input) Deviation
• Position: Latitude, Longitude and Elevation
• Event Time
• Status: Clock, Receiver, DCXO & EEPROM
• Configuration (1092B and 1093B/C)
A.6.5 Annunciators
• Operate (Green)
• Unlocked (Red)
