7.8.2 Programmable Pulse – Seconds–Per–Pulse Mode
Use the “Seconds–Per–Pulse” mode to generate a pulse every X number of seconds, from 1 to 60,000
seconds, and a Pulse Width of from 10 milliseconds to 600 seconds. Refer to Section 7.8 above for
additional detail on the Programmable Pulse mode. For RS-232 command, see Section 10.2.12.
SET PROG. PULSE?
ENTER
SETUP
PROG. PULSE MODE?
SEC. PER PULSE?
DOWN
UP
SET PULSE WIDTH?
PULSE WIDTH = 000.01
600.00
|
000.01*
SET SEC. PER PULSE?
00001 SEC.
60000
|
00001*
SELECT UTC OR LOCAL?
PULSE TIME = UTC
LCL
UTC*
* = Default Setting
(-) POLARITY?
(+) POLARITY?
SLOW CODE LCL?
SLOW CODE UTC?
SINGLE TRIGGER?
PULSE PER DAY?
PULSE PER HOUR?
SEC. PER PULSE? *
DOWN
UP
DOWN
UP
DOWN
UP
ENTER
ENTER
ENTER
ENTER
Figure 7.10: Seconds–Per–Pulse Setup
