3.2 Option 08, 10 to 60 VDC Terminal Power Strip 11
No. Country Specification Rating
P01 Continental Europe CEE 7/7 220V
P02 Australia, NZ, PRC AS3112-1981 240V
P03 U.K. BS 1363 240V
P04 Denmark Afsnit 107-2-01 240V
P05 India BS 546 220V
P06 Israel SI 32 220V
P07 Italy CEI 23-16/VII 1971 220V
P08 Switzerland SEV 1011.1959 220V
P09 North America and ROC NEMA 5-15P CSA C22.2#42 120V
P10 Japan JIS8303 120V
Table 3.1: Available IEC-320 Cordsets by Country
3.2 Option 08, 10 to 60 VDC Terminal Power Strip
This option replaces the standard power supply with one accepting 10 to 60 VDC (only), < 20 VA
typical. Replaces the standard IEC-320 inlet with a 3-pole terminal strip. Provides input surge
protection (SWC) for compliance with ANSI C37.90-1 and IEC 801-4. Option 08 operates from
common low-voltage battery systems, including 12, 24, and 48 VDC.
Figure 3.2: Option 08 Power Supply Inlet
Description
G – +
FUSE 1AT/250V
10 – 60 Vdc
DC ONLY
<20W Typ.
Ground Negative Positive Label
Fuse
3.2.1 Option 08, Connecting Inlet Power
When wiring station batteries to this power supply, make sure to first connect an earth ground
wire to the terminal strip connector labeled “G” (for ground). After connecting a ground wire,
connect the positive and negative leads from the station batteries to the corresponding Option 08
terminals. Figure 3.2 illustrates the Option 08 connector with terminals labeled as “+” and “–”.
3.3 Option 10, 110 to 350 VDC Terminal Power Strip
Figure 3.3 illustrates Option 10, which replaces the standard IEC-320 inlet with a 3-pole terminal
strip and provides input surge protection for compliance with ANSI C37.90-1 and IEC 801-4. Input
voltages are: 85 to 250 VAC, 47 to 440 Hz, or 110 to 350 VDC, < 20 VA typical.
