162 Options List
PTP Status Page
To view the PTP service, select PTP tab on the left and the Status tab above. Figure C.38
illustrates the status of PTP.
[Status] Configure
PTP Service : Enabled (Running)
Current UTC-PTP Offset : +35
ARBITER
SYSTEMS
Option 34 Network Time Module
NTP
[PTP]
SNMP
Clock
Network
System
Support
Logout
Computer Name (or IP address) – ssh – 80x24
Figure C.38: PTP Status Page Using SSH
Configure PTP Service
Please use the Web Interface to configure PTP. See Section C.15.3 for more information.
NTP Status Page
Use the cursor keys to select NTP, then Status and press ENTER. Figure C.39 illustrates the status
page for NTP.
[Status] Configure
NTP : Enabled (Running)
Root Dispersion : 0.451
Offset : 0.095
Frequency : 8.623
System Jitter : 0.008
Click Jitter : 0.010
Clock Wander : 0.001
Stratum : 1
ARBITER
SYSTEMS
Option 34 Network Time Module
[NTP]
PTP
SNMP
Clock
Network
System
Support
Logout
Computer Name (or IP address) – ssh – 80x24
Figure C.39: NTP Status Page Using SSH
