Model
Ordering code
Description
Sensor
1
2
3
4
5
Connection
D
DIN
A
ANSI
DS
DIN Flange St. St.
DSS
DIN St. St. body
AS
ANSI Flange St. St.
ASS
ANSI St. St. body
S
DIN 11851
SSS
DIN 11851 St. St. body
J
JIS
E
Table E
TD
Table D
T
Tri-clamp
W
Wafer
Size
10 / 3/8
200 / 8
10mm / 3/8"
200 mm / 8”
15 / 1/2
250 / 10
15mm / 1/2"
250 mm / 10”
20 / 3/4
300 / 12
20mm / 3/4"
300 mm / 12”
25 / 1
350 / 14
25mm / 1"
350 mm / 14”
32 / 1.1/4
400 / 16
32mm / 1.1/4"
400 mm / 16”
40 / 1.1/2
450 / 18
40mm / 1.1/2"
450 mm / 18”
50 / 2
500 / 20
50mm /2"
500 mm / 20”
65 / 2.1/2
600 / 24
65mm / 2.1/2"
600 mm / 24”
80 / 3
700 / 28
80mm / 3"
700 mm / 28”
100 / 4
800 / 32
100 mm/ 4"
800 mm / 32”
125 / 5
900 / 36
125 mm/ 5"
900 mm / 36”
150 / 6
1000 / 40
150 mm / 6”
1000 mm / 40”
Liner
HR
HARD RUBBER
PT
PTFE
SR
SOFT RUBBER
NR
HYGIENIC RUBBER
CT
E-CTFE
Pressure
150
150 psi
300
300 psi
10
PN10
16
PN16
25
PN25
40
PN40
Electrodes
SS
Stainless Steel
HA
Hastelloy C
TI
Titanium
PL
Platinum
Example
Sensor
D
100
HR
16
SS
