10. MAGX2 Error Code Table
MAGX2 can detect and show a number of errors in one error code value.
Error position
Error Description
0
Empty Pipe (Air Detect)
1
Overloaded
2
Excitation
3
Sensor not responding
4
SD open file
5
SD card not inserted
6
Write flash
7
ADC
8
GSM SMS Module Timeout
9
GSM SMS Module Low Signal
10
GSM SMS Module SIM card error
11
GSM SMS Module send SMS error
12
GSM SMS Module error
13
Very low or high temperature of the sensor
14
GPRS COMUNNICATION
15
GPRS CHECK
16
GPRS TIMEOUT
17
GPRS RESET
18
GPRS ECHO
19
GPRS SIM PIN
20
GPRS SIGNAL
21
GPRS CALL
22
GPRS IP
23
GPRS ONLINE
24
OVERLOAD 2
25-31
RESERVED (non-use)
Errors on the display are indicated in hex format. This number must be converted to
binary format! The MAGX2 software version 2.0.0.13 and newer decode and show error in
Real time measurement tab.
The error code has been converted to binary format, each position is related to a different error (see the table
above). Number 1 indicates error and number 0 indicates no error.
Example:
Error shown on display:
Error position:
Read errors:
083 HEX
100011 BIN
SD card not inserted / Overloaded / Empty pipe
Position 0
Position 1
Position 31
