CHAPTER 4 REFERENCE GUIDE
EFD1000 PRO MAX PFD Pilot’s Guide
Page 4-51
091-00005-002 ()
When the Weather is enabled, an age annunciation is shown in the lower left corner of
the Navigation Display (Figure 4-97). The age annunciation indicates the elapsed time in
minutes since the information was generated. Each weather product has an age limit and is
usually updated at the update frequency indicated in Table 4-8.
Age Annunciation Conditions
Weather data is being receive. “##”indicates the age of the
last valid data in minutes being displayed
Weather data is not being received but has not yet
expired. “##” indicates the age of the last valid data in
minutes being displayed. Check local weather conditions.
Weather data is not being received and the last valid data
is expired or invalid. Data is removed from the display.
Valid data has not yet been received from the NEXRAD
receiver after the PFD is turned on.
Table 4-8
Weather Age Annunciations
