4.4.3 Ground Speed
The Ground Speed (GS) comes from a configured GPS navigator and is digitally
displayed in the lower left corner of the Data Bar with a value range of 5–999 knots
or mph, using the same unit of measurement as the Airspeed Indicator.
4.4.4 Outside Air Temperature (when enabled)
The Outside Air Temperature (OAT) is displayed in the center of the Data Bar
(Figure 4-35). The temperature is obtained from the temperature sensor located
in the RSM. Temperature sensor ranges from -55°C to +80°C (-67°F to +176°F).
Set OAT Units of Measure
1. Press the MENU Button.
2. Rotate the Right Knob counterclockwise until GENERAL SETTINGS B
page displays.
3. Press the OAT Menu Key.
The Menu label turns magenta and the EDIT VALUE label displays above the Right Knob
(Figure 4-35).
4. Rotate the Right Knob to select either °C or °F (Figure 4-37).
5. Press the MENU Button to exit.
Figure 4-37
Select OAT Units of Measure
