CHAPTER 4 REFERENCE GUIDE
EFD1000 PRO MAX PFD Pilot’s Guide
Page 4-69
091-00005-002 ()
4.8.4 Advanced Autopilot Integration
When integrated with Autopilots which support it, the EFD1000 PRO MAX PFD can
display the Autopilot Mode Annunciations and control the Selected Altitude, Airspeed
and Vertical Speed targets in the PFD. The Annunication information displayed includes:
AP/FD Mode
Armed Lateral Mode
Active Lateral Mode
Active Vertical Mode
Armed Vertical Mode
Alert Annunciations
The specific modes that are display are dependent upon the specific autopilot installed.
Refer to the appropriate Autopilot Pilot guild for details.
Figure 4-111
Autopilot Intergration Display
