CHAPTER 4 REFERENCE GUIDE
EFD1000 PRO MAX PFD Pilot’s Guide
Page 4-38
091-00005-002 ()
Disable Auto Course
1. Press the MENU Button.
2. Rotate the Right Knob to the GENERAL SETTINGS A page (Figure 4-70).
3. Press the AUTOCRS Menu Key.
The Menu label turns magenta, and the EDIT VALUE label displays above the
Right Knob (Figure 4-71).
4. Rotate the Right Knob to select DISABLE (Figure 4-72).
5. Press the MENU Button to exit.
4.5.8 CDI Selected Course
When the CDI source changes from a GPS source with AUTOCRS to another CDI source,
the CRS value reverts to the last set value. When the CDI source is set to a VHF receiver
operating in the VOR or Localizer modes, editing the CRS value adjusts the current
selected CRS value. When the CDI source is set to a GPS receiver, and AUTOCRS is
disabled, the CRS value may be adjusted. When transitioning from GPS guidance to
VOR or localizer guidance, the course pointer should manually be set to the
appropriate course.
Select CDI Course
1. Press the Left Knob. The CRS label above the Left Knob and the Course field
are enabled for editing, both rendered in magenta (Figure 4-73).
2. Rotate the Left Knob to change the value of the Course field.
Once the CRS value is set, and after 10 seconds of inaction, the CRS field is disabled, and
both the label and field are rendered in cyan.
Figure 4-70
Menu, GENERAL SETTINGS
Figure 4-72
AUTOCRS Disabled
Figure 4-73
CRS Field Enabled for Editing
Figure 4-71
Editing AUTOCRS
