3.2 Quick Controls Overview
Chapter 2 explains the PFD controls in detail. The following is a quick summary:
Knobs
The Left or Right Knob each has a Home State, to which it returns after 10 seconds of
inactivity. The Left Knob is the CRS Knob, and the Right Knob is the HDG Knob.
• The current function of each knob is shown by its State, displayed
immediately above the knob. If the knob state is shown in magenta, turning
the knob will change the value of the function shown. If the legend is shown
in cyan or green, turning the knob will have no effect.
• From the Home State, pressing the knob once will enable the current
function to be set (Knob State color changes from cyan to magenta).
Successive presses of the knob will cycle through the functions that knob can
control. When the function you want to change is shown in magenta, turning
the knob will change its value.
• The Left Knob sets the Course Pointer (CRS, except when Auto Course Select
is enabled) and Indicated Airspeed Bug (IAS).
• The Right Knob sets Heading (HDG), Selected Altitude (ALT), Barometric
Pressure Setting (BARO), and Approach Minimums (MIN).
• Pressing and holding a knob syncs the selected function.
