CHAPTER 3 FLYING THE EFD1000 PRO PFD
EFD1000 PRO MAX PFD Pilot’s Guide
Page 3-4
091-00005-002 () EFD1000 PRO MAX PFD Pilot’s Guide
Page 3-5
091-00005-002 ()
Navigation Source Buttons
• Three Buttons at the bottom of the display couple the available navigation
sources to the CDI and the Bearing Pointers.
• The Center Button - CDI Navigation Source Select Button
• selects the nav source to couple to the CDI and to drive the autopilot
(if installed).
• The Left Button and Right Button select which nav source couples to each
of the two Bearing Pointers or none to hide the bearing pointers
Hot Keys
• The five keys on the lower right-hand side of the display are Hot Keys,
the function of which is shown by the legend on the screen immediately
adjacent to each key.
• The current status of each Hot Key is shown by the legend in a green label
and dark blue letters if active or in a blue label and green letters if inactive.
• Each press of a Hot Key will either toggle its function on or off or will cycle
among available settings.
NOTE
The tasks and procedures you will use in your airplane
will vary depending on your aircraft and equipment,
and on how they are configured and integrated with
the PFD in your specific installation
