CHAPTER 5 UNUSUAL CONDITIONS AND ANNUNCIATIONS
EFD1000 PRO MAX PFD Pilot’s Guide
Page 5-3
091-00005-002 ()
WARNINGS
Annunciation Description
Presented whenever the EFD system is operating on the internal battery or EBB. The countdown
timer appears first, and is then replaced by the ON BAT and % charge annunciation.
Attitude and Heading indications have failed.
Red chevrons displayed on the Attitude Indicator’s pitch scale to indicate extreme pitch up and
down attitudes .
Synthetic Vision Flight Path marker. Terrain or obstacle conflict within 30 seconds.
Radar Altitude Failed
