CHAPTER 5 UNUSUAL CONDITIONS AND ANNUNCIATIONS
EFD1000 PRO MAX PFD Pilot’s Guide
Page 5-7
091-00005-002 ()
CAUTION
Annunciation Description
The aircraft has reached or is below the set MINIMUMS. Accompanied by a one-second
stuttered tone when the optional tone generator is installed.
Accompanied by the following audible annunciation (at Minimums) “Minimums”
The aircraft is approaching (steady) or deviated from (flashing) the selected altitude.
Accompanied by a one-second steady tone when the optional tone generator is installed.
Accompanied by the following audible annunciation “Altitude”
The optional radar altimeter Decision height input indicates the aircraft is at or below the
radar altitude set by the pilot.
Indicates the GPSS source is invalid (e.g. the flight plan was deleted) or a different GPS was
selected by the pilot. The autopilot will fly wings-level until valid GPSS signal is available and
GPSS is re-engaged.
