CHAPTER 5 UNUSUAL CONDITIONS AND ANNUNCIATIONS
EFD1000 PRO MAX PFD Pilot’s Guide
Page 5-11
091-00005-002 ()
CAUTION
Annunciation Description
Green annunciation that indicates that the traffic sensor is enabled. ID after TFC indicates that
traffic identification is displayed if available.
This annunciation does not indicate the status of the ADS-B traffic data uplinked from the
ground.
Green annunciation that indicates that the traffic sensor is in standby.
Green annunciation that indicates that the TIS A traffic data has not been refreshed within
6 seconds.
Stormscope (strike) option: The rate indicates the approximate number of lightning strikes
detected per minute.
Stormscope (strike) option: Cell clustering display mode selected. The rate indicates the
approximate number of lightning strikes detected per minute.
