CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 PRO MAX PFD Pilot’s Guide
Page 2-6
091-00005-002 () EFD1000 PRO MAX PFD Pilot’s Guide
Page 2-7
091-00005-002 ()
sequence. Rotate the Right Knob to the left or right to decrease or increase the value
of selected field. Heading (HDG) is the default setting for the Right Knob.
Refer to Table 2-1 and (Figure 2-2)
• Rotate the Right Knob one click or Press the knob once to set the Selected
Heading Field/Heading Bug (HDG) (Refs. 52 and 53)
• Press the Right Knob twice to set the Selected Altitude Field (ALT)/Altitude
Bug (Refs. 22 and 26)
• When the MIN Hot Key is selected1, press the Right Knob three times to set
the Selected Minimums Field (MIN) (Ref. 28)
NOTE
When the CDI navigation source is selected to a GPS receiver and the Auto Course is
enabled in the Menu, the course is set automatically by the GPS and is not pilot-adjustable
(see Section 4.4.6). This state is indicated by the CRS field and Knob label shown in
green with an inverse “A”. In this case, pressing the Left Knob will enable you to set only the
Airspeed Bug (IAS).
