CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 PRO MAX PFD Pilot’s Guide
Page 2-12
091-00005-002 () EFD1000 PRO MAX PFD Pilot’s Guide
Page 2-13
091-00005-002 ()
Menu Name Menu Item Description OPTIONS
GENERAL SETTINGS -C MACH DISP Altitude or MACH number when display switches
to MACH instead of TAS on the Data Bar
OFF,
Altitude: ON>5K, ON>6K, ON>7K, ON>8K,
ON>9K, ON>10K, ON>11K, ON>12K, ON>13K,
ON>14K, ON>15K, ON>16K, ON>17K, ON>18K,
Mach Number: ON>0.1, ON>0.2, ON>0.3,
ON>0.4, ON>0.5, ON>0.6, ON>0.7
GENERAL SETTINGS -C OVERSPEED WARN TEST Issues an Overspeed Warning Audio test Press to Test
GENERAL SETTINGS -C SEL ALT ARC Enables the display of the Altitude intercept Arc on
the HSI/CDI
ON, OFF
SV SETTINGS DB EXP: XX XXX XX Displays the experation data for the currently load
Navigation Database
n/a
SV SETTINGS TERR WRN SYS (TWS) Inhibits the Terrian Warning System ON, INH, SV ONLY
SV SETTINGS SV APT FLG DISP Enables displaying the Airport Identifier flag when in
Synthetic Vision mode
ALL ON, NONE, FP APT ONLY, ON>4500,
ON>4000, ON>3500, ON>3000, ON>2500, ALL
HRD SFC
SV SETTINGS FLIGHT PLATH MARKER Enabled display of the Flight Path Marker when in
Synthetic Vision Mode
ENABLE, DISABLE
SV SETTINGS TERR EFF XX XXX XX Displays the Effectivity date for the currently load
Terrian Database
n/a
360 MAP SETTINGS 360 DCLTR LVL Declutter Level used when drawing the basemap
when in 360 mode
0, 1, 2, 3, 4
360 MAP SETTINGS 360 FLT PLN Flight Plan is displayed on the basemap when in
360 mode
OFF, AUTO
360 MAP SETTINGS 360 APTS Airports are displayed on the basemap when in 360
mode
OFF, AUTO
