CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 PRO MAX PFD Pilot’s Guide
Page 2-16
091-00005-002 () EFD1000 PRO MAX PFD Pilot’s Guide
Page 2-17
091-00005-002 ()
Menu Name Menu Item Description OPTIONS
XM RECEIVER C CA CVRG AGE XX Age of the Candada Coverage Weather data in
Minutes
n/a
XM RECEIVER C HOLD FOR WX LGND Displays the XM Weather Legend Press/Hold to Display
UAT UAT STATUS UAT STATUS n/a
UAT UAT CODE: --- Manual UAT Ident setting (only with certain UAT
installations and only if automatic Transponder
connection fails)
4 digit ident
UAT PUSH TO IDENT Manual “Push to Ident” on the UAT (only with certain
UAT installations and only if automatic Transponder
connection fails)
Press to send Ident
UAT HORZ VECT SCALE Adjust the length of the displayed Traffic velocity
vector
0,10,20,30,40,50,60 Sec
UAT HOLD FOR WX LGND Displays the ADS-B Weather Legend Press/Hold to Display
POWER SETTINGS BATTERY Switches the EFD from External Power to Battery
power
Press to switch to Battery Pwr
POWER SETTINGS EXT POWER Switches the EFD from Battery Power to External
Power (IF external power is valid)
Press to switch to External Pwr
POWER SETTINGS RESTART Causes the EFD to shutdown and restart. Press to Restart
POWER SETTINGS EXT PWR: XX.XV External Power Volage n/a
POWER SETTINGS BAT: XXXXXXX Battery Status n/a
