CHAPTER 3 FLYING THE EFD1000 PRO PFD
EFD1000 PRO MAX PFD Pilot’s Guide
Page 3-2
091-00005-002 () EFD1000 PRO MAX PFD Pilot’s Guide
Page 3-3
091-00005-002 ()
FEATURE FEATURE
Selected Altitude
Barometric Pressure
(BARO) Hot Key
Map RNG (Range)
Buttons
Left and Right Buttons,
Bearing Pointers Nav
Source
1
Barometric Pressure
Setting Field
CDI Navigation Source
Select (Middle Button)
Heading Bug Value
Selected Course (CRS)
Pointer Field
1
Compass Mode Hot
Key: 360 or ARC
MINIMUMS Setting
1
GPS Steering
(GPSS) Hot Key
Selected Airspeed
Table 3-1 Basic PFD Settings
Figure 3-1
Basic PFD Settings
