D21 18
253
White
P098
1
098
1
Engine oil level #1 low-data valid but below
normal operational range-most severe level
X
254
None
S017
4
632
4
Fuel stop valve circuit-voltage below normal, or
shorted to low source
X
259
Red
S017
7
632
7
Fuel stop valve-stuck at open position
X
261
White
P174
0
174
0
Fuel temperature high - data valid but above
normal operational range-moderately severe
level
X
263
Amber
P174
3
174
3
Fuel temperature sensor circuit-voltage above
normal, or shorted to high source
X
265
Amber
P174
4
174
4
Fuel temperature sensor circuit-voltage below
normal, or shorted to low source
X
292
white
P223
14
1083
14
Auxiliary temperature sensor input #1 engine
protection- data valid but above normal
operational range- most severe level
X
293
Amber
P223
3
1083
3
Auxiliary temperature sensor input #1 circuit-
voltage above normal, or shorted to high
source
X
294
Amber
P223
4
1083
4
Auxiliary temperature sensor input #1
circuit-voltage below normal, or shorted to low
source
X
296
White
P223
14
1084
14
Auxiliary pressure sensor input #2 engine
protection - data valid but above normal
operational range -most severe level
X
297
Amber
P223
3
1084
3
Auxiliary pressure sensor input #2
circuit-voltage above normal, or shorted to high
source
X
298
Amber
P223
4
1084
4
Auxiliary pressure sensor input #2
circuit-voltage below normal, or shorted to low
source
X
299
None
S117
14
1384
31
J1939 send engine stop instruction
X
316
Amber
S078
3
931
3
Fuel delivery pump actuator circuit-voltage
above normal, or shorted to high source
X
318
Amber
S078
7
931
7
Fuel delivery pump actuator-mechanical block
X
343
Amber
S254
12
629
12
Engine control module-warning internal
hardware failure
X
346
Amber
S253
12
630
12
Engine control module- warning software
failure
X
