Atlas Copco Dynapac F3030C User Manual

D21 19
349
Amber
P191
0
191
0
Gearbox output shaft (tail shaft) speed high-
data valid but above normal operational
range-moderately severe level
X
384
Amber
S237
11
626
11
Start auxiliary device control circuit fault (diethyl
ether spray)
X
415
white
P100
1
100
1
Engine oil pressure low-data valid but below
normal operational range-most severe level
X
422
Amber
P111
2
111
2
Engine coolant level senor circuit-data erratic,
intermittent, or incorrect
X
423
Amber
P156
2
156
2
Fuel timing pressure or timing actuator-block
X
426
Amber
S231
2
639
2
SAE J1939 data communication
interface-unable communicate
X
427
None
S231
639
9
SAE J1939-not fast enough
X
431
Amber
P091
2
91
2
Accelerator pedal or lever idle validation
circuit-data erratic, intermittent, or incorrect
X
432
Red
P091
13
91
13
Accelerator pedal or lever idle validation circuit-
out of calibration
X
441
None
P168
1
168
1
Accumulator #1 voltage low- data valid but
lower normal operational range-moderately
severe level
X
442
Amber
P168
0
168
0
Accumulator #1 voltage high- data valid but
above normal operational range-moderately
severe level
X
451
Red
P157
3
157
3
Oil atomizer measuring pipe #1 pressure
sensor circuit-voltage above normal, or shorted
to high source
X
452
Red
P157
4
157
4
Oil atomizer measuring pipe #1 pressure
sensor circuit-voltage below normal, or shorted
to low source
X
455
Red
S018
3
633
3
Fuel control valve circuit- voltage above
normal, or shorted to high source
X
467
Amber
S020
2
635
2
Timing oil pipe actuator circuit- data erratic,
intermittent, or incorrect
X
468
Amber
S018
2
633
2
Fuel oil pipe actuator circuit- data erratic,
intermittent, or incorrect
X
471
Maintain
P098
1
98
1
Engine oil level low-maintain
X
472
Maintain
P017
2
1380
2
Engine oil level #2 low-maintain
X
