F40
8
Seals and sealing rings (5)
After
rea
ching op
erating
tempera
ture,
check t
he gearb
ox for leaks.
In case
of visibl
e leaks
, e.g.
between th
e
flan
ge surfaces (A) of the
gearbox,
replace
m
ent o
f
the se
als and sealing
rings
is necess
ary
.
