D11 18
Item
Designation
Brief description
22 Left conveyor control switch
Pushbutton function:
- Left conveyor manually or
automatically conveying front
outwards.
For triggering conveyor
function, conveyor pushbutton
function must be switched to
“AUTO” or “MANUAL”.
Conveyor speed under
“MANUAL” mode equals to the
highest speed under “AUTO”
mode.
To work under “AUTO” mode,
drive lever must be put into
