D11 31
5 Left screed extend/retract switch
Botton at left position: the left
side of telescoping screed
extending to the outside;
Botton at right position: the left
side of telescoping screed
retract inwards;
6
Left auger speed preseletor,
manual
“MANUAL” mode, use this
button to control auger speed;
left side speed is the lowest,
right side speed is the highest.
7 Left conveyor pushbutton, manual
When material is unsufficient,
press this button for material
conveying, release the button
when material is sufficient.
8 Horn
Press in case of emergencies
and indicate when vechile starts
to move!
