FlexiROC T30 R 19 Automatic Central Lubrication System CLS
131 No: 3629357835.1.3629419915 en-US
19 Automatic Central Lubrication
System CLS
19.1 Automatic Central Lubrication System CLS
A Pump element
B Safety valve
C Plug (timer for pause and running time)
D Filler nipple
E Reservoir
19.2 Pause Time and Running Time Settings
Integrated in the lubrication pump is a timer which controls pause and running times. To
access the timer, remove the plug on the lubrication pump.
