FlexiROC T30 R 10 Hydraulic System
68 No: 3629357835.1.3629419915 en-US
10.7.7 Check Lubricant Tank Level
!
NOTE: Bleeding of the lubrication system is necessary if all the oil is drained out of it.
Precondition
p
The level must not be below 40 mm (1.6").
n
Check the tank and connections for signs of leakage.
n
Refill with lubricant if necessary. Always use a funnel with strainer when refilling.
10.8 Hydraulic Filters
10.8.1 Return Oil Filter
The return oil filter cleans the oil before it returns to the tank. The filter cartridges should be
replaced according to the maintenance schedule. If the return filter pressure gauge on the
operator display indicates a clogged filter, all return oil filters must be changed immedi-
ately.
Symbol for Clogged Filter
