6.
Push the button for damper flow pressure on the operator panel.
7.
Adjust the damper pressure on the constant flow valve. Undo the locking screw (B) on
the constant flow valve. Adjust the damper pressure with knob (A), clockwise to re-
duce pressure and counterclockwise to increase pressure.
