SYSTEM DESIGN
710-14888-00C EMX4i User Manual 11
 Inside delta installation
3.0-10:350
3.5-15:345
4.0-10:350
4.0-20:340
5.0-5:355
EMX4i-0024B 36 30 28 24 25
EMX4i-0042B 63 51 51 40 48
EMX4i-0052B 78 63 58 52 51
3.0-10:590
3.5-15:585
4.0-10:590
4.0-20:580
5.0-5:595
EMX4i-0064B
96
94
90
76
81
EMX4i-0069B
103
103
103
93
97
EMX4i-0105B 157 129 126 103 115
EMX4i-0115B 172 162 157 129 142
EMX4i-0135B 202 193 189 154 172
EMX4i-0184B 276 216 208 174 190
EMX4i-0200B
300
256
247
207
225
EMX4i-0229B
343
291
280
235
255
EMX4i-0250B 375 366 345 300 303
EMX4i-0352B 528 430 415 351 387
EMX4i-0397B 595 484 466 394 433
EMX4i-0410B 615 615 615 570 600
EMX4i-0550B 825 790 759 640 696
EMX4i-0580B
870
868
832
705
762
