SYSTEM DESIGN
12 EMX4i User Manual 710-14888-00C
NEMA motor ratings
All ratings are calculated at altitude of 1000 metres and ambient temperature of 50 ºC.
Light
300%, 10 s,
6 starts per hour
Normal
350%, 30 s,
4 starts per hour
Heavy
450%, 30 s,
4 starts per hour
A
HP
@230
VAC
HP
@460
VAC
HP
@575
VAC
A
HP
@230
VAC
HP
@460
VAC
HP
@575
VAC
A
HP
@230
VAC
HP
@460
VAC
HP
@575
VAC
EMX4i-0024B 24 7.5 15 20 17 5 10 15 14 3 10 10
EMX4i-0042B 42 15 30 40 28 10 20 25 22 7.5 15 20
EMX4i-0052B 52 15 30 50 35 10 25 30 28 10 20 25
EMX4i-0064B
64
20
50
60
52
15
30
40
40
10
25
30
EMX4i-0069B
69
25
50
60
59
20
40
50
46
15
30
40
EMX4i-0105B 100 30 75 100 77 25 50 60 52 15 40 50
EMX4i-0115B 115 40 75 100 81 30 60 75 65 20 50 60
EMX4i-0135B 135 50 100 125 99 30 75 100 77 25 60 75
EMX4i-0184B 164 60 125 150 124 40 75 100 96 30 60 75
EMX4i-0200B 200 75 150 200 131 50 100 125 104 40 75 100
EMX4i-0229B
229
75
150
200
156
60
125
150
124
40
100
100
EMX4i-0250B
250
100
200
250
195
75
150
200
156
60
125
150
EMX4i-0352B 341 125 250 350 240 75 150 200 180 60 150 150
EMX4i-0397B 389 150 300 400 261 100 200 250 203 75 150 200
EMX4i-0410B 410 150 300 450 377 150 300 350 302 100 250 300
EMX4i-0550B 550 200 450 500 414 150 350 450 321 125 250 300
EMX4i-0580B 580 200 500 500 477 200 400 500 361 150 300 350
