PROGRAMMABLE PARAMETERS
710-14888-00C EMX4i User Manual 93
10F – Current Calibration
Range:
85% - 115%
Default:
100%
Description:
Calibrates the soft starter's current monitoring circuits to match
an external current metering device.
Use the following formula to determine the necessary
adjustment:
Calibration (%) = Current shown on EMX4i display
Current measured by external device
10G – Adjustment Lock
Options:
Read & Write
(default)
Allows users to alter parameter values in the
main menu.
Read Only
Prevents users altering parameter values in
the main menu. Parameter values can still be
viewed.
Description:
Selects whether the keypad will allow parameters to be
changed via the main menu.
10H – User Parameter 1
Options:
Blank
Displays no data in the selected area,
allowing long messages to be shown without
overlapping.
Current (default) Average rms current across all three phases
Motor Voltage
Average rms voltage across all three
phases.
P1 Voltage Phase 1 voltage.
P2 Voltage Phase 2 voltage.
P3 Voltage
Phase 3 voltage.
Mains Frequency
The average frequency measured on three
phases.
Motor pf
The motor's power factor, measured by the
soft starter.
Motor Power The motor's running power in kilowatts.
Motor
Temperature (%)
The motor's temperature, calculated by the
thermal model.
Hours Run
The number of hours the motor has run via
the soft starter.
Number of Starts
The number of starts the EMX4i has
completed since the start counter was last
reset.
