AUDAC M2 User Manual

14
Relay outputs:
Inadditiontothestandardaudiooutputs,theM2alsocontains 8 relay outputs.Eachof
theserelayscontainnormallyclosed(NC)andnormallyopen(NO)contactswhichcanbe
connectedusingTerminal Block connectors.
Theserelayscanbetriggeredautomatically when a paging message is announcedfor
acertainzone,whenapriority signal or contact occurs,atpredefined timer scheduled
momentsorbypushing freely programmable buttons on a paging console.
Averydiverserangeofexternaldevicescanbecontrolledusingtheserelays.Sometypical
applicationexamplesareoverrulingmanual100Voltvolumecontrollersandactivating
emergencylightsincaseofemergencycalls.Otheroptionsareswitchingonpoweramplifiers
atpredefinedmoments,powering-updisplaysorbeamerstogetherwiththeaudiosystem,
rollingandunrollingofautomaticprojectionscreens,turninglightsonandoff,...
Infact,theserelayoutputscanbeusedforcontrollingandpoweringdevicesinamuchwider
applicationrangethandescribedabove,aslongasthevoltageandcurrentdonotexceed
theallowedlimitof1A / 30V DC or 0.3 A / 125V AC.
Contact inputs:
Atotalof10 contact inputsareprovided,whichcanbeusedfortriggeringalldifferent
kindsofactionsandeventsbyasimple contact closure.Someexamplesoftriggerable
actionsare ‘Scenes’ selection, Output zones linking, priority actions triggering,
voice file enabling, ...
Eightoftheseinputsaregroupedunder‘Contact Inputs’andimplementedusinga
9-PinsTerminalBlockconnector.Thesecontactscanbetriggeredbyconnectingthe
common(C)terminalwiththecorrespondingterminal(1to8)ofthecontactsinput.
Theother twocontactinputsaregroupedunder‘Priority Inputs’andimplementedusing
2-PinsTerminalBlockconnectors.Thesecontactscanbetriggeredbyconnectingboth
terminalpinstoeachother.
Priority inputs:
Two balanced priority audio inputsarefeaturedusing3-PinsTerminal Block
connectors.ThesepriorityaudioinputsacceptbothLineandMicrophonelevelsignals
andcanbeusedforconnectinganymonoaudiosourcedevicesuchasexternalvoicefile
interfaces,telephonepageroutputs,...
Theactionstobetakenincaseofapriorityinputcanbefreelyprogrammedand
configuredforeachoutputindividually.
Peripheral interface connectors:
Atotalof10 Peripheral interface connectorsarepresent,providedwithRJ45
connectors.ThisallowsexpansionofthesystemwithperipheralunitssuchasWallPanel
controllers(possiblycontainingadditionallocalaudioinputs),digitalpagingmicrophones,
intelligentrelayunits,...
AllthePI ports (1 to 10)supportbidirectional RS485 data transferupto32 devices
connectedtoeach PI port,whileonlythe8firstPI ports (1 to 8)supportdata + digital
audio transfer. Thisway,audioinputscanbeconnected,whichcanbepatchedtothe
mixer.

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
