AUDAC M2 User Manual

15
Onlyone audio input device(data+digitalaudiotransfer)canbeconnectedtoeach PI
port (ports 1 to 8)whilemultiple control devices(upto32)canbeconnectedtoeach
PI port (ports 1 to 10)usingbuscabling(connectingdevicesinparallel).
Besides,thesupplyvoltagetotheperipheralinputsisalsoprovidedonthePeripheral
interfaceconnectors.(insomecasesanadditionalpowersupplyisdesirable)
RS232 Connection:
TheRS232connectioncanbeusedtocontrolthemixerthroughexternalhardwaresuch
ashomeautomationsystemsorcomputers.Connectyourexternalcontrolhardwareto
thisport.Thepinoutandcommunicationsettingsaredescribedinanearlierchapterof
thisusermanual(Chapter1:Connections&Connectors).ThecompleteRS232command
instructionsetandconfigurationinformationcanbedownloadedfromtheAUDACwebsite.
Remote control (Ethernet) Connector:
TheM2canbeconnectedthroughEthernetusingthisRJ45connector.Thisway,the
mixercanbecontrolledbysendingcommandsoverTCP/IP,and/orbyusingtheintegrated
web-basedinterfacewhichcanbeaccessedthroughanydeviceusingastandardweb-
browsersupportingflashorspecialappsthataredesignedforuseincombinationwith
mobileapplications.(Smartphones&Tablets).
IftheM2isconnectedtoalocalLANnetwork(connectedtoarouter/switch/hub)a
straightnetworkcableisnecessary.Whenconnecteddirectlytoacomputer,acrossed
networkcableshouldbeused.
FormoreinformationabouttheEthernetconfigurationofthisdevice,check‘Chapter4:
Userinterface&Configuration’and‘Chapter9:IPBasics’ofthisusermanual.
Optical link in & output connectors (optional)
ThetwoST/PCconnectorspresentontheoptionalFiberInterconnectionModule(OPT2)
canbeusedforcreatinglinksbetweenseveralmatrixsystems,coveringdistancesup
to1000metersandtransferringupto16audiochannels(8Stereo)usingoneduplex
multimodeglassfibercable.
Power inlet:
Themainpowersupply(110~240VAC/50~60Hz)hastobeappliedtothisACpower
inlet.TheconnectionismadebyanIECpowerconnectorandisfittedwithafuse.When
replacingthefuse,makesurethatthevalueofthereplacementfusematchesthevalueof
theoriginalfuse.(T2AL/250V)
NOTE: WheninstallingtheoptionalPowerAmplifierkit,thefuseneedstobechanged
accordinglyandshouldbereplacedbyaT4AL/250Vfuse(includedwithPOW2).

AUDAC M2 Specifications

General

Monitor out	1
Number of Euroblock input connectors	20
Number of Euroblock output connectors	24
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
DJ mixer	No
Rack capacity	19U
Rack mounting	Yes
Channels quantity	- channels
Digital sound processing	- bit
Equalizer bands quantity	5

Weight and Dimensions

Depth	350 mm
Width	482 mm
Height	132 mm
Weight	8850 g
