Version 7.2 1049 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
BellcoreCallerIDTypeOneSubStandard parameter. To select
the ETSI Caller ID substandard, use the
ETSICallerIDTypeOneSubStandard parameter.
 To select the Bellcore MWI sub standard, use the
BellcoreVMWITypeOneStandard parameter. To select the
ETSI MWI sub standard, use the
ETSIVMWITypeOneStandard parameter.
 If you define Caller ID Type as NTT [2], you need to define
the NTT DID signaling form (FSK or DTMF) using the
NTTDIDSignallingForm parameter.
Enable FXS Caller ID Category
Digit For Brazil Telecom
fxs-callid-cat-brazil
[AddCPCPrefix2BrazilCallerID]
Enables the interworking of Calling Party Category (cpc) code
from SIP INVITE messages to FXS Caller ID first digit.
 [0] Disable (default)
 [1] Enable
When the parameter is enabled, the device sends the Caller ID
number (calling number) with the cpc code (received in the SIP
INVITE message) to the device's FXS port. The cpc code is
added as a prefix to the caller ID (after IP-to-Tel calling number
manipulation). For example, assuming that the incoming INVITE
contains the following From (or P-Asserted-Id) header:
From:<sip:+551137077801;cpc=payphone@10.20.7.35>;t
ag=53700
The calling number manipulation removes "+55" (leaving 10
digits), and then adds the prefix 7, the cpc code for payphone
user. Therefore, the Caller ID number that is sent to the FXS
port, in this example is 71137077801.
If the incoming INVITE message doesn't contain the 'cpc'
parameter, nothing is added to the Caller ID number.
CPC Value in
Received INVITE
CPC Code Prefixed
to Caller ID (Sent to
FXS Endpoint)
Description
cpc=unknown 1 Unknown user
cpc=subscribe 1 -
cpc=ordinary 1 Ordinary user
cpc=priority 2 Pre-paid user
cpc=test 3 Test user
cpc=operator 5 Operator
cpc=data 6 Data call
cpc=payphone 7 Payphone user
Note:
 The parameter is applicable only to FXS interfaces.
 For the parameter to be enabled, you must also set the
parameter EnableCallingPartyCategory to 1.
[EnableCallerIDTypeTwo] Disables the generation of Caller ID type 2 when the phone is
off-hooked. Caller ID type 2 (also known as off-hook Caller ID) is
