Version 7.2 1173 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
Conference ID
configure voip > gateway dtmf-
supp-service supp-service-settings
> conf-id
[ConferenceID]
Defines the Conference Identification string.
The valid value is a string of up to 16 characters. The default is
"conf".
Note: To join a conference, the INVITE URI must include the
Conference ID string preceded by the number of the
participants in the conference and terminated by a unique
number. For example:
INVITE sip:4conf1234@10.1.10.10
INVITE messages with the same URI join the same
conference.
Automatic Gain Control (AGC) Parameters
Enable AGC
configure voip > media ipmedia >
agc-enable
[EnableAGC]
Global parameter enabling the AGC feature.
You can also configure the functionality per specific calls, using
Tel Profiles (TelProfile_EnableAGC). For a detailed description
of the parameter and for configuring the functionality in the Tel
Profiles table, see Configuring Tel Profiles on page 428.
Note: If the functionality is configured for a specific Tel Profile,
the settings of the global parameter is ignored for calls
associated with the Tel Profile.
For a description of AGC, see Automatic Gain Control (AGC)
on page 204.
AGC Slope
configure voip > media ipmedia >
agc-gain-slope
[AGCGainSlope]
Determines the AGC convergence rate:
 [0] 0 = 0.25 dB/sec
 [1] 1 = 0.50 dB/sec
 [2] 2 = 0.75 dB/sec
 [3] 3 = 1.00 dB/sec (default)
 [4] 4 = 1.25 dB/sec
 [5] 5 = 1.50 dB/sec
 [6] 6 = 1.75 dB/sec
 [7] 7 = 2.00 dB/sec
 [8] 8 = 2.50 dB/sec
 [9] 9 = 3.00 dB/sec
 [10] 10 = 3.50 dB/sec
 [11] 11 = 4.00 dB/sec
 [12] 12 = 4.50 dB/sec
 [13] 13 = 5.00 dB/sec
 [14] 14 = 5.50 dB/sec
 [15] 15 = 6.00 dB/sec
 [16] 16 = 7.00 dB/sec
 [17] 17 = 8.00 dB/sec
 [18] 18 = 9.00 dB/sec
 [19] 19 = 10.00 dB/sec
 [20] 20 = 11.00 dB/sec
 [21] 21 = 12.00 dB/sec
 [22] 22 = 13.00 dB/sec
 [23] 23 = 14.00 dB/sec
 [24] 24 = 15.00 dB/sec
