User's Manual 328 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
3. Configure a SIP Interface according to the parameters described in the table below.
4. Click Apply.
Table 17-5: SIP Interfaces table Parameter Descriptions
Parameter Description
SRD
srd
[SIPInterface_SRDName]
Assigns an SRD to the SIP Interface.
If only one SRD is configured in the SRDs table, the SRD is
assigned to the SIP Interface by default. If multiple SRDs are
configured in the SRDs table, no value is defined and you must
assign an SRD.
To configure SRDs, see ''Configuring SRDs'' on page 317.
Note:
 The parameter is mandatory.
 You can assign the same SRD to multiple SIP Interfaces (SBC
and Gateway).
General
Index
[SIPInterface_Index]
Defines an index for the new table row.
Note: Each row must be configured with a unique index.
Name
interface-name
[SIPInterface_InterfaceName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 21 characters. By default, if you do
not configure a name, the device automatically assigns the name
"SIPInterface_<row index>" (e.g., "SIPInterface_1" when added to
Index 1).
Topology Location
topology-location
[SIPInterface_TopologyLocati
on]
Defines the display location of the SIP Interface in the Topology
view.
 [0] Down = (Default) The SIP Interface element is displayed on
the lower border of the view.
 [1] Up = The SIP Interface element is displayed on the upper
border of the view.
For more information on the Topology view, see ''Building and
Viewing SIP Entities in Topology View'' on page 355.
