AudioCodes MSBG Series User Manual

Version 7.2 755 Mediant 1000B Gateway & E-SBC
User's Manual 43. Software Upgrade
Note: If you have configured regular IP-to-Tel manipulation rules (see ''Configuring
Source/Destination Number Manipulation'' on page 503), the device applies these
rules before applying the mapping rules of the User Info table.
• Tel-to-IP Calls: Maps the calling (source) PBX extension to the "global" number.
For example, if the device receives a Tel call from PBX extension 402, it changes
this calling number to 638002, and then sends call to the IP side with this calling
number. In addition to the "global" phone number, the display name (caller ID)
configured for the PBX user in the User Info table is used in the SIP From header.
Note: If you have configured regular Tel-to-IP manipulation rules (see ''Configuring
Source/Destination Number Manipulation'' on page 503), the device applies these
rules before applying the mapping rules of the User Info table.

Registering Users: The device can register each PBX user configured in the User
Info table. For each user, the device sends a SIP REGISTER to an external IP-based
Registrar server, using the "global" number in the From/To headers. If authentication
is necessary for registration, the device sends the user's username and password,
configured in the User Info table, in the SIP MD5 Authorization header.
You can configure up to 1,000 mapping rules in the GW User Info table. These rules can
be configured using any of the following methods:

Web interface - see ''Configuring GW User Info Table through Web Interface'' on page
755

CLI - see Configuring GW User Info Table through CLI on page 757

Loadable User Info file - see ''Configuring GW User Info Table in Loadable Text File''
on page
758
Note:
• To enable user registration, configure the following parameters:
√ 'Enable Registration': Enable (IsRegisterNeeded is set to 1).
√ 'Registration Mode': Per Endpoint (AuthenticationMode is set to 0).
• For FXS ports, when the device needs to send a new SIP request with the
Authorization header (e.g., after receiving a SIP 401 response), it uses the
username and password configured in the Authentication table (see Configuring
Authentication per Port on page 579). To use the username and password
configured in the User Info file, set the 'Password' parameter to any value other
than its default value.
43.1.8.2.1 Configuring GW User Info Table through Web Interface
The following procedure describes how to configure and register users in the GW User Info
table through the Web interface.
