T
able 4:
Setting values
Default values f
or European
variant
Menu
Parameter
s
Yellow
Green
Yellow/green
Yellow
M0838
Colour
ind.light
1
Red
Blue
Purple
Red
M0839
Colour
ind.light
2
Red
Yellow
Orange
Red
M0840
Colour
ind.light
3
Red
Blue
Purple
Red
M0841
Colour
ind.light
4
Green
Red
Orange
Green
M0842
Colour
ind.light
5
Information
Def
ault values can v
ar
y f
or other variants.
24
Actuator controls
Indications
A
C 01.2/ACExC 01.2 Profinet
23
25
Table of Contents
Default Chapter
2
Table of Contents
2
Assignment of Analogue Output 1
2
Signal Range of Analogue Output 1
2
Adjustment of Analogue Output 1
2
Safety Instructions
8
Prerequisites for the Safe Handling of the Product
8
Range of Application
9
Warnings and Notes
9
References and Symbols
9
Short Description
10
Operation
11
Operating the Actuator from Local Controls
11
Actuator Operation from Remote
11
Menu Navigation Via Push Buttons (for Settings and Indications)
12
Menu Layout and Navigation
13
User Level, Password
14
Password Entry
14
Password Change
14
Timeout for Incorrect Password Entry
15
Language in the Display
15
Language Change
15
Indications
17
Indications During Commissioning
17
Indications in the Display
17
Feedback Signals from Actuator and Valve
18
Status Indications According to AUMA Classification
20
Status Indications According to NAMUR Recommendation
21
Indication Lights of Local Controls
23
Indication Lights: Change Colour
23
Signals (Output Signals)
25
Signals Via Profinet
25
Status Signals Via Output Contacts (Digital Outputs)
25
Assignment of Outputs
25
Coding the Outputs
25
Configurable Status Signals
25
Analogue Signals (Analogue Outputs)
26
Assignment of Analogue Output 1
26
Signal Range of Analogue Output 1
27
Adjustment of Analogue Output 1
28
Operation
30
Operation Mode off
30
Operation Mode Local
30
Push-To-Run Operation or Self-Retaining Local
30
Operation Mode Remote
31
Push-To-Run Operation or Self-Retaining Remote
31
Operation Mode EMERGENCY
32
Operation Mode EMERGENCY Stop
32
Operation Mode Disabled
32
Operation Mode Service
32
Basic Settings for Commissioning
34
Type of Seating for End Positions
34
Type of Seating: Set
34
Torque Switching
35
Torque Switching: Set
36
Limit Switching
37
Limit Switching: Set
37
End Position Setting Via Stroke
39
Date and Time
42
Display Formats
42
Date Format
42
Time Format
43
Number Format
43
Torque Unit
43
Temperature Unit
43
Position Units
43
Process Factor Units
44
Analogue Working Value Units (AIN)
45
Analogue Signal Output Units (AOUT)
45
Contrast
46
Application Functions
47
Intermediate Positions
47
Intermediate Positions of Pivot Points: Define
47
Signal Behaviour of Intermediate Positions: Set
47
Hysteresis for Intermediate Positions: Set
48
Operation Profile (Operation Behaviour) for Intermediate Positions
49
Operation Profile: Activate
49
Operation Profile for Intermediate Positions (Pivot Points): Set
49
Off Times for Intermediate Positions (Pivot Points): Set
50
Two-Wire Control
50
Positioner (Operation Mode Remote SETPOINT)
51
Positioner: Activate
51
Adaptive Behaviour: Activate Deactivate
51
Overrun (Inner Dead Band): Set Manually
52
Max. Error Variable (Outer Dead Band): Set Manually
52
Dead Time: Set
53
Hysteresis for Positioner: Set
53
Closing Fully/Opening Fully (End Position Tolerance for Setpoint)
53
Setting Range: Limit
53
Change-Over between OPEN - CLOSE Control and Setpoint Control
54
Input of Setpoint Position
55
Input Range of Setpoint Position
55
Split Range Operation
56
Process Controller
57
Process Controller Activation
58
Process Controller: Set Modulating Behaviour
58
Setpoint Source (Input for Process Setpoint)
59
Behaviour on Loss of Process Setpoint
59
Inverse Operation
59
Internal Process Setpoint
60
Setting Procedure
60
Proportional Gain Kp: Set
60
Reset Time Ti: Set
60
Rate Time Td: Set
61
Actual Value Source (Input for Actual Process Value)
61
Stepping Mode
61
Stepping Mode: Activate
62
Operation Mode for Stepping Mode
62
Start and End of Stepping Mode
63
On Times and off Times
63
Profinet Addressing Device Name Assignment
63
Additional Inputs for Fieldbus
64
Combination of Fieldbus-Parallel Interface
64
Auto Change-Over I/O (During Fieldbus Failure)
65
By-Pass Function
66
By-Pass Function: Activate
67
By-Pass Application: Configure
68
Lift Plug Valve (LPV)
68
LPV Function: Activate
70
LPV Actuator Type: Configure
70
Delay Time of LPV Master Actuator: Configure
71
Delay Time of LPV Slave Actuator: Configure
71
Automatic Deblocking
71
Automatic Deblocking Function: Activate
72
Operation Time for Operation in Opposite Direction: Set
72
Number of Deblocking Attempts: Set
72
Tolerance Range: Set
73
Heater System and Heaters
73
Heater System Within the Actuator Controls
73
Heater on Control Unit (Actuator)
73
Motor Heater
74
Failure Functions
75
Reversing Prevention Time
75
Failure Behaviour on Loss of Signal
75
Failure Reaction on Loss of Signal
75
Failure Source (Failure Reason) for a Failure Operation: Set
76
Failure Operation (Reaction of the Actuator) on Loss of Signal
76
Preset Position: Define
77
Failure Position MPV: Define
77
Delay Time: Set
77
EMERGENCY Behaviour
77
EMERGENCY Behaviour: Activate
78
EMERGENCY Failure Reaction
79
Failure Source (Failure Reason) for an EMERGENCY Operation: Set
79
Operation Mode for EMERGENCY Behaviour
80
EMERGENCY Operation
80
EMERGENCY Position
80
EMERGENCY Position MPV
80
Torque Switching: By-Pass
81
Motor Protection: By-Pass
81
Stepping Mode: By-Pass
81
Operation Profile: By-Pass
81
Interlock: By-Pass
82
Local Stop: By-Pass
82
Delay Time for EMERGENCY Operation
82
Enable Local Controls
82
Enabling Function: Activate
83
Enabling Function Behaviour
83
Priority REMOTE
84
Priority REMOTE: Activate
85
Priority REMOTE Behaviour
85
Fieldbus Auto Enable
85
Interlock (Enabling Operation Commands)
85
Interlock: Activate
86
Source of Interlock Enable Signal: Set
86
Operation Mode for Interlock
87
Interlock Behaviour (Running Direction)
87
Local Stop
87
Behaviour
87
EMERGENCY Stop Function
88
Partial Valve Stroke Test (PVST)
88
PVST Activation
89
PVST Source: Set
90
Operation Mode for PVST
90
Behaviour for PVST: Define
90
Partial Stroke for PVST: Set
90
PVST Monitoring Time: Set
91
PVST Operating Time: Set
91
PVST Reversing Time: Set
91
PVST Reminder
91
Bluetooth Interface Can be Activated and Deactivated
92
Monitoring Functions
95
Torque Monitoring
95
Torque By-Pass
95
Torque Limitation of Torque By-Pass
96
Motor Protection Monitoring (Thermal Monitoring)
97
Type of Duty Monitoring (Motor Starts and Running Time)
97
Operating Time Monitoring
99
Reaction Monitoring
99
Motion Detector
100
Activate Motion Detector
100
Detection Time Dt
100
Travel Difference DX
101
Delay Time
101
Monitoring of Electronics Power Supply
101
Temperature Monitoring
102
Heater System/Heater Monitoring
102
Verification of Sub-Assemblies
103
Phase Failure Monitoring
103
Phase Sequence Detection and Correction of the Direction of Rotation
104
Functions: Activate and Enable
105
Functions: Activate
105
Functions: Enable
105
Multiport Valve
107
Actuator Type: Set/Check
107
Gear Reduction Ratio: Set/Check
107
Number of Ports (Positions)
108
Home Port (Zero Position): Set
108
Positions (of Valve Ports): Define/Check
109
Operate to Position Via Push Buttons of the Local Controls
109
Operate to Position from Remote
111
Dead Band
112
Correction of Inertia
112
12.1.10. Backlash Compensation
112
12.1.11. Signalling Behaviour of Positions: Set/Check
112
12.1.12. Hysteresis for Signalling Intermediate Positions: Set
113
Product Variants
107
Direction of Rotation
114
Factory Setting
114
Service Functions
114
Data Export
115
Data Import
115
Languages: Reload
115
Actual Configuration: Accept
116
Firmware Update
116
Service Software
116
Bluetooth Connection Diagnostic
118
Diagnostics
118
Electronic Device ID
118
Diagnostic Interface
119
Diagnostic Position Transmitter RWG
120
Position Transmitter and Potentiometer Diagnostic
120
Diagnostic on Time Monitoring
121
Diagnostic Position Transmitter MWG
121
Diagnostic Positioner
121
Diagnostic Process Controller
122
Profinet Interface: Diagnostics
122
14.10.1. Diagnostic
122
Diagnostic FQM (Fail Safe)
122
Simulation (Inspection and Test Function)
123
14.12.1. Actuator Signals
123
14.12.2. Interface Signals
123
Asset Management
125
Operating Data
125
Event Report
126
Characteristics
127
Torque-Travel Characteristic
127
Position-Time Characteristic
129
Temperature-Time Characteristic
130
Histograms
130
Motor Running Time-Position (Histogram)
130
Motor Running Time-Temperature (Histogram)
131
Motor Running Time-Torque (Histogram)
132
Maintenance (Information and Signals)
132
Operating Times Display
134
Device Temperature Display
134
Corrective Action
135
Primary Fuses
135
Fault Indications and Warning Indications
135
Appendix
143
Selection Overview for Output Contacts and Indication Lights (Digital Outputs DOUT)
143
Selection List of Binary Signals for Digital Inputs (DIN)
147
Index
150
Parameter Index
154
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the AUMA AC 01.2 and is the answer not in the manual?
Ask a question
AUMA AC 01.2 Specifications
General
Brand
AUMA
Model
AC 01.2
Category
Control Unit
Language
English
Related product manuals
AUMA Aumatic AC 01.1
112 pages
AUMA AMExC 01.1
60 pages
AUMA AUMATIC AC 01.2
92 pages
AUMA Matic
4 pages
AUMA ACV 01.2
168 pages
AUMA ACVExC 01.2 Series
144 pages
AUMA AUMATIC ACExC 01.2
92 pages
AUMA ACE C 01.2 Profinet Series
76 pages
AUMA AM 01.1
84 pages
AUMA AM 02.1
92 pages
AUMA AMB 01.1
96 pages
AUMA MATIC AM 01.1
20 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
