8. Application functions
Definition
Application functions are functions used to adapt the actuator controls to special
applications.This includes device functions, communication functions and device
information.
If they are enabled, these functions can be programmed by the user for his/her
specific task using parameters.
8.1. Intermediate positions
Conditions
The actuator is equipped with a position transmitter.
Characteristics
●
With the actuator controls, up to 8 intermediate positions can be set to any
value between 0 % and 100 % of the travel.
●
Each intermediate position can be activated or deactivated individually.
●
When reaching an intermediate position, a signal can be generated.
●
A hysteresis can be defined for each pivot point.
8.1.1. Intermediate positions of pivot points: define
Each intermediate position can be set to a value between 0 and 100 % of the travel.
Customer settings M0041
Intermediate positions M0143
Pivot points M0160
Pivot point 1 M0249
Default values: 0.0 % for all 8 intermediate positions
Setting range: 0.0 % (CLOSED) to 100.0 % (OPEN) of the travel
Information
The pivot points also apply to the <Operation profile> function.
8.1.2. Signal behaviour of intermediate positions: set
Reaching a pivot point (intermediate position) can be signalled:
●
via fieldbus (refer to separate operation instructions)
●
via indication lights (LEDs) of the local controls or
●
via output contacts
Each pivot point (intermediate position) can be assigned a specific signal behaviour.
Customer settings M0041
Intermediate positions M0143
Signal behaviour M0266
Signal behaviour 1 M0269
Default value: No signal
Setting values:
No signal
Behaviour A: “Off”, intermediate position is not signalled.
C________|¯¯¯¯¯¯¯¯O
Behaviour B: Signal is active from reaching the pivot point (P) up to end position
OPEN (100 %)
C¯¯¯¯¯¯¯¯¯|_______O
Behaviour C: Signal is active from end position CLOSED (0 %) until reaching the
pivot point (P).
C_______|¯|_______O
Behaviour D: When passing the pivot point (P), a pulse signal is issued.
47
Actuator controls
AC 01.2/ACExC 01.2 Profinet Application functions
