Activate position unit
Required user level: Specialist (4) or higher.
Display M0009
Units M1205
Position M1206
Position activation M1207
Default value: Function not active
Setting values:
Function not active
<Units of position> function deactivated. Position indications in the display (e.g. the
valve position S0001) are indicated in percent.
Function active
<Units of position> function activated. Position indications in the display are not
shown in percent but in the unit set for the values in parameter group Position.
Set max. value, scaling and unit
Required user level: Specialist (4) or higher.
Display M0009
Units M1205
Position M1206
Max. value at 100.0 % M1208
Scaling M1209
Unit M1210
Default values:
Max. value at 100.0 % = 1000
Scaling = 1
Unit = mA
Setting ranges/values:
Max. value at 100.0 % = 1 1000
Scaling = 0.001 1000 (multiplier factor for unit)
Unit = mA; °C; bar; m³/h; m³/min; m; cm; mm; °
7.5.7. Process factor units
Process factors (e.g. process setpoint, actual process value...) are shown in percent
of travel in the actuator controls display (default setting). By activating the parameter
Process factor, you may select other physical units apart from percent.The
change-over affects all screens indicating a process value.
Activate process factor units
Required user level: Specialist (4) or higher.
Display M0009
Units M1205
Process factor M1211
Proc. var. activation M1212
Default value: Function not active
Setting values:
Function not active
<Process factor units> deactivated. Position indications in the display are shown in
percent.
Function active
<Process factor units> activated. Position indications in the display are not shown
in percent but in the unit set for the values in parameter group Process factor.
Set max. value, scaling and unit
Required user level: Specialist (4) or higher.
44
Actuator controls
Basic settings for commissioning AC 01.2/ACExC 01.2 Profinet
