Enable/disable local controls via fieldbus commands
For control via fieldbus interface, the command for enabling the local controls is done
via fieldbus command Fieldb. enable LOCAL.
Switching behaviour:
Fieldb. enable LOCAL = 1 = enable:
Operation via local controls enabled
Fieldb. enable LOCAL = 0 = disabled:
Operation via local controls disabled
Information
In the event of loss of fieldbus communication, the local controls will be disabled
since no enable signal is present.
If operation commands are not transmitted via fieldbus commands, but via <Additional
inputs> or an additional <Parallel interface>, a digital input has to be available and
configured to enable/disable the local controls.
Configuration of digital input
Required user level: Specialist (4).
Device configuration M0053
I/O interface M0139
Digital inputs M0116
Example
Use input DIN 5 for signal Enable Local:
Parameters: Signal DIN 5 M0122
Setting value: Enable Local (wiring diagram designation: Enable LOCAL)
Information
The logic for the digital inputs may be inverted. Depending on the parameter setting
(e.g. Coding DIN 5 M0127), the input is either High active or Low active. Default
setting is High active.
Enable/disable local controls via digital input
Switching behaviour for coding High active:
Input Enable Local = high level (standard: +24 V DC):
Operation via local controls enabled
Input Enable Local = low level (0 V DC or input open):
Operation via local controls disabled
9.4.1. Enabling function: activate
Required user level: Specialist (4) or higher.
Device configuration M0053
Application functions M0178
Activation M0212
Enable LOCAL M0631
Default value: Function not active
Setting values:
Function not active
Function <Local controls: enable from REMOTE> deactivated.
Function active
Function <Local controls: enable from REMOTE> activated.
9.4.2. Enabling function behaviour
The enable behaviour determines which selector switch functions (LOCAL, OFF)
require an additional enable signal.
Required user level: Specialist (4) or higher.
Customer settings M0041
Local controls M0075
83
Actuator controls
AC 01.2/ACExC 01.2 Profinet Failure functions
