Configuration of tripping time
Required user level: Specialist (4) or higher.
Device configuration M0053
Phase monitoring M0170
Tripping time M0172
Default value: 10.0 s
Setting range: 1.0 – 300.0 s
Information
Faults in supply voltage (e.g. voltage drops) do not generate a fault signal during the
adjustable tripping time.
10.12. Phase sequence detection and correction of the direction of rotation
Conditions:
The phase sequence detection is only valid for connections to 3-phase AC power
supplies. For versions with 1-phase AC or DC, phase sequence detection is not
possible.
Properties
Exchanging any two phase conductors in the 3-phase mains changes the direction
of phase rotation. Should phases L1, L2 and L3 be connected in the wrong sequence,
this is detected and corrected by the AUMATIC: This prevents the actuator to rotate
in the incorrect direction.
Activate phase sequence detection and correction of direction of rotation
Device configuration M0053
Phase monitoring M0170
Adapt rotary dir. M0171
Default value: Function active
Setting values:
Function active
Function <Phase sequence detection and correction of direction of rotation> is
activated.
Function not active
Phase sequence detection and correction of direction of rotation is deactivated.
104
Actuator controls
Monitoring functions AC 01.2/ACExC 01.2 Profinet
