Stepping mode is active in the operation modes: Remote, Remote II, Fieldbus
Local
Stepping mode is active in the operation modes: Local, Service
Remote and local
Stepping mode is active in the operation modes: Remote, Remote II, Fieldbus, Local,
Service
Information
The timer cannot be by-passed in <Operation mode EMERGENCY>.
8.6.3. Start and end of stepping mode
Start and end of stepping mode can be individually set for both directions.
Customer settings M0041
Timer M0142
End stepping CLOSE M0152
Start stepping CLOSE M0153
Start stepping OPEN M0154
End stepping OPEN M0155
Default values:
End stepping CLOSE = 0.0 %
Start stepping CLOSE = 100.0 %
Start stepping OPEN = 0.0 %
End stepping OPEN = 100.0 %
Setting ranges:
End stepping CLOSE = 0.0 – 99.9 %
Start stepping CLOSE = 0.1 – 100.0 %
Start stepping OPEN = 0.0 – 99.9 %
End stepping OPEN = 0.1 – 100.0 %
8.6.4. On times and off times
On or off times can be set individually for directions OPEN and CLOSE.
Customer settings M0041
Timer M0142
On time CLOSE M0163
Off time CLOSE M0164
On time OPEN M0165
Off time OPEN M0166
Default values: 00:05.0 min : s (= 5 seconds; for all on and off times)
Setting ranges: 00:01.0 ... 00:05.00.0 min : s (= 1 second up to 30 minutes; for all
on and off times)
8.7. Profinet addressing – device name assignment
The device name is assigned to the device during device name assignment. The
acyclic communication is IP based and allows the use of known IT mechanisms via
protocols such as UDP or TCP/IP, while cyclic Profinet real-time data as well as
event-based alarms are exclusively based on the most widely used network
technology, Ethernet with MAC addressing and message prioritisation. The MAC
address is inseparably linked to the device and unique around the world. Using the
DCP protocol (Discovery) and the device name, the controller will identify the network
participants and will assign their IP addresses. As an alternative, the IP address may
also be assigned manually.
Profinet participants are therefore addressed by means of the parameters below:
●
Unique MAC address
●
Assigned device names
●
Assigned IP address
Device name and, as an option, also the IP address, is assigned by the software
used for configuration of the network topology, e.g. Siemens Step7/TIA or Proneta
63
Actuator controls
AC 01.2/ACExC 01.2 Profinet Application functions
