Enabling may be activated or deactivated individually for operation commands
OPEN and CLOSE.
●
Enabling can be set for the different operation modes.
Enable/disable operation commands via fieldbus commands
For control via fieldbus interface, the commands for enabling the operation commands
is done via commands Fieldb. enable OPEN or Fieldb. enable CLOSE.
Switching behaviour:
●
Fieldb. enable OPEN or Fieldb. enable CLOSE = 1 = enabled:
Operation command enabled.
●
Fieldb. enable OPEN or Fieldb. enable CLOSE = 0 = disabled:
Operation command disabled.
If operation commands are not transmitted via fieldbus commands, but via <Additional
inputs> or an additional <Parallel interface>, a digital input has to be available and
configured to enable/disable the local controls.
Configuration of digital input
Required user level: Specialist (4).
Device configuration M0053
I/O interface M0139
Digital inputs M0116
Example
Use input DIN 5 to enable operation commands in direction CLOSE:
Parameter: Signal DIN 5 M0122
Setting value: Enable CLOSE (wiring diagram designation: Interlock CLOSE)
Information
The logic for the digital inputs may be inverted. Depending on the parameter setting
(e.g. Coding DIN 5 M0127), the input is either High active or Low active. Default
setting is High active.
Enable/disable commands via digital input
Switching- behaviour for coding High active:
●
Input Enable OPEN = low level (0 V DC or input open):
Operation command enabled.
●
Input or Enable OPEN = high level (default: +24 V DC):
Operation command disabled,
9.6.1. Interlock: activate
Required user level: Specialist (4) or higher.
Device configuration M0053
Application functions M0178
Activation M0212
Interlock M0663
Default value: Function not active
Setting values:
Function not active
Function <Interlock (enable operation commands)> deactivated.
Function active
Function <Interlock (enable operation commands)> activated.
9.6.2. Source of Interlock enable signal: set
Customer settings M0041
Interlock M0664
Interlock source M1013
Default value: Active comm. source
86
Actuator controls
Failure functions AC 01.2/ACExC 01.2 Profinet
