14.9. Diagnostic Process controller
Required user level: Specialist (4) or higher.
Diagnostics M0022
Process controller M0883
Menu M0883 is only visible if function Process controller M0741 is activated.
The following states can be checked via diagnostic:
SignificationMenu IDParameters
M0884Process setpoint
M0885Actual process value
M0886Op. com. PID contr.
14.10. Profinet interface: diagnostics
This diagnostics provides information on the current status of the Profinet
sub-assemblies.
Required user level: Specialist (4) or higher.
Diagnostics M0022
Profinet M1807
Device identification M1820
Communication status M1817
I&M 0 M1819
14.10.1. Diagnostic
Various Profinet interface states can be checked via the menu Diagnostics M0022.
The <Information on Profinet> table shows the menus for the Profinet interface.
Table 20: Information on Profinet
Value and descriptionIndication on display
Manufacturer ID
Vendor ID M1834
Ident code
IDENT Code M1821
Manufacturer name
Manufcturer name M1822
Profinet device type
Profinet device type M1953
Profinet device name
Profinet dev. name M1856
IP address
IP address M1841
Subnet mask
Subnet mask M1849
Gateway
Gateway M1850
MAC address of Profinet module
MAC address module M1851
MAC address of Profinet port 1
MAC address port 1 M1852
MAC address of Profinet port 2
MAC address port 2 M1853
Firmware version of Profinet module
FW version module M1865
Device is currently used to exchange data (DataEx) connection to I/O controller active and valid
data received by I/O controller
Channel 1 DataEx M1808
Activity of communication interface on channel/port 1 available data blocks are detected
Channel 1 activity M1809
Activity of communication interface on channel/port 2 available data blocks are detected
Channel 2 activity M1860
Network status
Network status M1818
Status of Profinet module or Profinet connection
Module status M1854
Configuration error of module
Config. error module M1855
The Profinet module is not available
Fieldbus mod. not avail. M1859
14.11. Diagnostic FQM (fail safe)
The menu will only be visible if a fail safe unit (FQM) is connected to the actuator.
122
Actuator controls
Diagnostics AC 01.2/ACExC 01.2 Profinet
