This prevents end position(s) OPEN and/or CLOSED from being approached in
modulating duty. The actuator stops when reaching the set limit value.
For OPEN-CLOSE control (LOCAL or REMOTE OPEN-CLOSE operation mode),
this limitation is not active.The valve can then be run into the end positions either
via the local controls or from remote.
Figure 36: Limitation of setting range
[1] Permissible actuator travel for setpoint control
[2] Permissible actuator travel for OPEN-CLOSE control
Activate limitation
Customer settings M0041
Positioner M0145
Limit setting range M0845
Default value: Function not active
Setting values:
Function not active
Limitation deactivated.
Function active
Limitation activated.
Adjust setting limits
Parameters
Customer settings M0041
Positioner M0145
Limit OPEN M0162
Limit CLOSE M0161
Default values:
Limit OPEN = 100.0 %
Limit CLOSE = 0.0 %
Setting ranges: 0.0 ... 100.0 % of setting range
8.4.9. Change-over between OPEN - CLOSE control and setpoint control
For actuators equipped with a positioner, it is possible to change over between OPEN
- CLOSE control (Remote OPEN-CLOSE) and setpoint control (Remote
SETPOINT).
Change-over via fieldbus command:
For control via fieldbus interface, the change-over is done via fieldbus command
Fieldbus SETPOINT.
Switching behaviour:
Fieldbus SETPOINT = 0 = Remote OPEN-CLOSE:
The actuator reacts to operation commands OPEN, STOP, CLOSE
Fieldbus SETPOINT = 1 = Remote SETPOINT:
The actuator reacts to a setpoint signal (e.g. 0,0 ... 100,0 %)
If the operation commands are not transmitted via fieldbus commands, but via
<Additional inputs> or additional <Parallel interface>, a digital input for the MODE
signal has to be available and configured for change-over.
54
Actuator controls
Application functions AC 01.2/ACExC 01.2 Profinet
