AUMA AM 01.1 User Manual

Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
≤ 2 000 m above sea level
> 2,000 m above sea level, please contact AUMA
Installation altitude
Refer to name plate of actuator controlsAmbient temperature
IP68Standard:Enclosure protection according to
EN 60529
DS Terminal compartment additionally sealed against interior (double sealed)Option:
According to AUMA definition, enclosure protection IP68 meets the following requirements:
●
Depth of water: maximum 8 m head of water
●
Duration of continuous immersion in water: Max. 96 hours
●
Up to 10 operations during continuous immersion
●
Modulating duty is not possible during continuous immersion.
For exact version, refer to actuator controls name plate.
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree according to
IEC 60664-1
1 g, from 10 to 200 Hz
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be
derived from this. (Not valid in combination with gearboxes)
Vibration resistance according to
IEC 60068-2-6
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and
high pollution.
Options:
KX-G: Same as KX, however aluminium-free version (outer parts)
Double layer powder coating
Two-component iron-mica combination
Coating
AUMA silver-grey (similar to RAL 7037)Standard:Colour
Available colours on requestOption:
Accessories
For AM mounted separately from the actuator, including plug/socket connector. Connecting cable on
request. Recommended for high ambient temperatures, difficult access, or heavy vibration during service.
Cable length between actuator and AM max. 100 m. Not suitable for version with potentiometer in the
actuator. Instead of the potentiometer, the actuator has to be equipped with an electronic position
transmitter.
Wall bracket
Further information
Approx. 7 kg (with AUMA plug/socket connector)Weight
Electromagnetic Compatibility (EMC): (2014/30/EU)
Low Voltage Directive: (2014/35/EU)
Machinery Directive: (2006/42/EC)
EU Directives
72
SA 07.2 – SA 16.2 /SAR 07.2 – SAR 16.2
Technical data AM 01.1/AM 02.1

AUMA AM 01.1 Specifications

General
