75
and save the setting, and return to the Live Data screen, or tap Cancel to exit
without saving.
Clear Data — tap this button to clear all cached live data.
Freeze — displays the retrieved data in freeze mode.
⚫ Previous Frame — moves to the previous frame of frozen data.
⚫ Next Frame — moves to the next frame of frozen data.
⚫ Play/Pause — tap to play/pause the frozen data.
⚫ Resume — tap to exit the freeze data mode and return to normal data display.
Record — starts recording the live data of the selected data items. Tap the Record
button at the bottom of the Live Data screen. A message will display prompting the
user to select parameters to record. Tap the Got It button to confirm. Scroll down
and select data to record. Tap the Record button to start recording. Tap the
Resume button to stop recording. The recorded live data can be viewed in the
Review section at the bottom of the Live Data screen. The recorded data can also
be reviewed in the Data Manager application.
⚫ Resume — tap this button to stop data recording and return to normal data
display.
⚫ Flag — this button displays when the Record function is applied. Tap this
button to set flags when recording data. Notes can be added during playback
in Review or Data Manager. Select the preset flag to open a pop-up window
and display a virtual keyboard to enter notes.
Review — review the recorded data. Tap the Review button to display a recording
list, and select one item to review.
NOTE
Only the data recorded during the current operation can be reviewed on the Live Data
screen. All the historical recorded data can be reviewed in Review Data in the Data
Manager application.
⚫ Previous Frame — switches to the previous frame of recorded data.
⚫ Next Frame — switches to the next frame of recorded data.
⚫ Play/Pause — tap to play/pause the recorded data.
⚫ Show Selected — displays the selected parameters.
⚫ Graph Merge — merges selected data graphs.
⚫ Back — exits the review and returns to the Live Data screen.
Back — returns to the previous screen or exits the function.
