5.4.2 Screen Messages
Screen messages will appear when additional input is needed before proceeding.
There are three main types of on-screen messages: Confirmation, Warning, and Error.
5.4.2.1 Confirmation Messages
Confirmation messages inform you when you are about to perform an action that
cannot be reversed or when an action has been initiated and confirmation is needed to
continue.
When a user-response is not required to continue, the message will display briefly.
5.4.2.2 Warning Messages
This type of messages displays a warning that a selected action may result in an
irreversible change or loss of data. An example of this type of message is the “Erase
Codes” message.
5.4.2.3 Error Messages
Error messages display when a system or procedural error has occurred. Examples of
possible errors include cable disconnection or communication interruption.
5.4.3 Making Selections
The Diagnostics application is a menu-driven program that presents a series of choices.
Once a selection has been made, the next menu in the series is displayed. Each
selection narrows the focus and leads to the desired test. Tap the screen to make menu
selections.
5.5 Diagnostic Function Entrance
The Diagnostics application enables a data link to the electronic control system of the
test vehicle for vehicle diagnosis. The application performs function tests, retrieves
vehicle diagnostic information such as trouble codes and live data from various vehicle
control systems like engine, transmission, and ABS.
There are two options available when accessing the diagnostic function:
1. Auto Scan — starts auto scanning for all the available systems on the vehicle.
2. Control Unit — displays a selection menu for all available control units of the test
vehicle.
After a selection is made and the tablet establishes communication with the vehicle, the
corresponding function menu or selection menu will display.
