4.4.1 Top Toolbar Buttons
The top toolbar contains a number of buttons. See Table 5-2 Diagnostics Toolbar
Buttons on page 61 for details.
4.4.2 Navigation Tab
The navigation tab at the top of the main section contains the following items:
1. Check Tab — displays the triggered sensor data.
2. Diagnostics Tab — checks the status of the TPMS system. This function is
available for certain vehicles.
3. Programming Tab — displays the triggered/retrieved sensor IDs and new
programmed sensor IDs.
4. Relearn Tab — displays the OEM sensor manufacturer, part number, and sensor
frequency, and performs the relearn procedures.
NOTE
Not all vehicles support Diagnostics function. If the selected vehicle model does not
support Diagnostics, this tab will not appear on the screen.
4.4.3 Main Section
The main section of the screen varies depending on the stage of operations. It can
show the TPMS sensor conditions, such as sensor ID, pressure, temperature, battery
status, and the specific relearn procedures.
4.4.4 Function Buttons
The displayed function buttons at this section of the screen varies depending on the
stage of operations. They can be used to trigger the TPMS sensor, create sensor IDs,
program MX-Sensor, read and clear codes, and return to the previous screen or exit the
function. The functions of these buttons will be introduced respectively in the following
sections.
4.5 TPMS Check
The sensor check function allows the activation of TPMS sensor to view sensor data
such as sensor ID, tire pressure, sensor frequency, tire temperature, sensor battery,
and sensor position. It also sends the sensor data to vehicle’s ECU to let the ECU learn
the positions of sensors whenever wheels are rotated or sensors are replaced.
